OMNITRONIC PAS-215 MK3 2-Way Top
OMNITRONIC PAS-215 MK3 2-Way Top
OMNITRONIC PAS-215 MK3 2-Way Top
OMNITRONIC PAS-215 MK3 2-Way Top
OMNITRONIC PAS-215 MK3 2-Way Top
OMNITRONIC PAS-215 MK3 2-Way Top

OMNITRONIC PAS-215 MK3 2-Way Top

SKU: 11039482

557,93 €
IVA included.
Contact

Add to wishlist



Passive speaker with 15" woofer, 1" driver and 400 W RMS

  • 2-way bass-reflex system with 38 cm woofer (8 cm voice coil)
  • 2.5 cm compression driver with ferrite magnet (3.8 cm voice coil with polymer diaphragm)
  • Optimized for combination with PAS subwoofers
  • With rigging points
  • Black metal grille with acoustic foam
  • 2 mould carrying handles
  • Dual flange

Package contents

  • 1 x user manual, 1 x compact cabinet speaker


Power:Program: 800W
Rated: 400W RMS
Frequency range:50 - 20000 Hz
Sensitivity:99 dB (1W/1m)
Max. SPL:127 dB
Dispersion angle:90° x 60°
Impedance:8 ohms
Attachment system:Dual flange: Ø 35mm (0°/5°)
Flying points:4 x M10 thread; 6 x M8 thread
Connections:Input: speaker via 2 x speaker built-in socket (F)
Crossover frequency:3000 Hz
Speaker:1 x compression tweeter highs (1") approx. 2.5 cm with ferrit magnet
Basket material: aluminum
Voice coil compression tweeter highs (1.5") approx. 4 cm
Horn vent (1") approx. 2.5 cm
1 x woofer (15") approx. 38 cm with ferrit magnet
Voice coil lows (3") approx. 8 cm
Type of speaker:Compact cabinet speaker
Mould carrying handle:2 pc/pcs
Material:Birch multiplex
Color:Black, textured coating, painted
Dimensions:Width: 45 cm
Depth: 69,5 cm
Height: 43,5 cm
Weight:24,20 kg
Brand Omnitronic
