EUROLITE LED PLL-576 CW/WW Panel
EUROLITE LED PLL-576 CW/WW Panel
EUROLITE LED PLL-576 CW/WW Panel
EUROLITE LED PLL-576 CW/WW Panel
EUROLITE LED PLL-576 CW/WW Panel
EUROLITE LED PLL-576 CW/WW Panel

EUROLITE LED PLL-576 CW/WW Panel

SKU: 40001899



DMX-controlled surface light with 576 dual white LEDs, QuickDMX port, diffuser and barn doors

  • 288 powerful LEDs 0,5 W SMD 5730 warm white (WW)
  • 288 powerful LEDs 0,5 W SMD 5730 cold white (CW)
  • Variable color temperature 3000 K - 6000 K
  • Additional frost filter provides a wide, soft and homogeneous light
  • 4 barn doors to avoid blinding the audience and for protection during transport
  • Direct color temperature selection for 69 preset values
  • Dimmer electronic
  • Flicker-free
  • With a beam angle of 120°
  • The device is cooled by temperature-controlled fan
  • Very high color rendering index (CRI)
  • LCD display
  • Rubber feet
  • Control via DMX; Master/slave function; stand-alone; Quick select potentiometer for brightness and color temperature; CRMX by LumenRadio via USB (optional); QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional)
  • With Mounting bracket
  • For application areas such as: Video and photography; Stage; Trade fair and shop fitting; Rental
  • Mains input and output for power linking up to 8 units
  • Preprogrammed in Light Captain
  • Very quiet working noise
  • Application possibility: Suspended; standing; on tripod

Package contents

  • 1 x spotlight, 1 x user manual, 1 x power cord, 1 x diffusor cover, 4 x knurled screw


Power supply:100-240 V AC, 50/60 Hz
Power consumption:160 W
IP classification:IP20
Protection class:Protection class I
Power connection:Mains input via P-Con (blue), mounting version power supply cord with safety plug
Power output:1 x P-Con (gray), mounting version
Lamp type:LED lamp
LED:288 x 0,5 W SMD 5730 cold white (CW)
288 x 0,5 W SMD 5730 warm white (WW)
Color temperature:3000K - 6000K adjustable
DMX channels:2-1; 2-2; 3-1; 3-2; 4
DMX input:3-pin XLR (M) mounting version
5-pin XLR (M) mounting version
DMX output:3-pin XLR (F) mounting version
5-pin XLR (F) mounting version
Cooling:Temperature-controlled fan
Control:DMX; Master/slave function; stand-alone; Quick select potentiometer for brightness and color temperature; CRMX by LumenRadio via USB (optional); QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional)
Preprogrammed in:Light Captain
Beam angle:120°
Beam angle (1/2 peak):120°
Color rendering index (CRI):93 Ra
Illuminance in Lux (lx):Cold white (CW) 1m: 3752 lx, 3m: 453 lx, 6m: 134 lx
Warm white (WW) 1m: 3664 lx, 3m: 445 lx, 6m: 132 lx
All 1m: 5667 lx, 3m: 690 lx, 6m: 204 lx
Housing color:Black
Attachment system:Mounting bracket
Display type:LCD display
Transport aid:Rubber feet
Dimensions:Length: 44 cm
Width: 19,8 cm
Height: 22,3 cm
Weight:6,00 kg
Noise classification:Class 1 (very slight noise, suitable for noise-sensitive environments)
Legal specifications
Special product:Not designed for household room illumination
Intended use:Show effect lighting
