ANTARI Z-350 Fazer

The Z-350 is stemming from years of experience in Fazer development. The adoption of the air pump technology not only enables the Z-350 to generate dry haze but also provides its heater with a self-cleaning function. The Z-350 comes with a larger tube of one diameter, which substantially reduces the risk of heater clogging.An extremely low fluid consumption rate grants a full tank (1.3 liters) of the Z-350 to produce more than 7 hours of non-stop hazing at maximum output.The new on-board DMX interface allows users smarter control of the Z-350: When a DMX signal is received, the machine powers up and starts heating up automatically. When the DMX signal is off, it automatically begins the self-cleaning process and then goes into Sleep mode.The machine weighs only 8.7 kg. Being so light and compact allows the Z-350 to be transported and setup anywhere-whenever needed.

Extremely efficient fazer with DMX interface

• Extremely low fluid consumption rate grants a full tank to produce more than 7 hours of non-stop hazing at maximum output
• Produces fine, translucent haze without nebulizing the room at the same time
• Ideal for accentuating light and laser beams
• Combines the reliability of a fog machine with the extremely silent operation of a haze machine
• Fan speed and output volume variably adjustable via onboard controls
• Self-cleaning function
• When the DMX signal is off, it starts the self-cleaning process and then goes into standby mode
• Short warm-up time
• Control via wired remote control (optional); stand-alone; DMX
• With level indication
• Operates on water-based fluid
• Water-based fluid ready for use
• For application areas such as: Clubs/dancing school; Wedding/gala/events; Stage; Rental
• Application possibility: Standing

Package contents

• 1 x device, 1 x user manual, 1 x power cord

Power supply:	230 V AC, 50 Hz
Power consumption:	690 W
IP classification:	IP20
Protection class:	Protection class I
Power connection:	Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided)
Warm-up time:	Approx. 4 min
Output volume:	Approx. 85 m³/min
Tank capacity:	1,3 l water-based fluid fixed tank
Fluid consumption:	Approx. 3 ml/min
DMX channels:	2
DMX input:	1 x 3-pin XLR (M) mounting version
DMX output:	1 x 3-pin XLR (F) mounting version
Control:	Wired remote control (optional); stand-alone; DMX
Housing color:	Grey
Operating principle:	Vaporizing fog machine
Type of fluid:	Water-based fluid ready for use
Heater:	800 W
Color:	Grey
Dimensions:	Width: 32 cm Depth: 15 cm Height: 39 cm
Weight:	8,80 kg
Noise classification:	Class 2 (slight noise)
