EUROLITE LED TMH-46 Moving-Head Wash
SKU: 51785892
Compact moving washlight with 6in1 LEDs
- 4 powerful LEDs 10 W high-power 6in1 HCL RGBWA/UV (homogenous color mix)
- Positioning within 540° PAN and 220° TILT
- Exact positioning (16 bit resolution)
- Motion macros adjustable; Dimmer electronic; color blend stepless; color macros adjustable
- Strobe effect
- Integrated show programs
- The device is cooled by cooling fan
- Control via DMX; stand-alone; Sound to light via Microphone; Master/slave function
- Flicker-free
- With a beam angle of 24°
- 4 digit 7-segment LED display
- Preprogrammed in Light´J; LED PC-Control 512; EASY SHOW 1; Light Captain
- For application areas such as: Clubs/dancing school; Party room; mobile djs/entertainer; restaurants, bars and hotels
- Application possibility: Standing; suspended
Package contents
- 1 x moving light, 1 x user manual, 1 x power cord, 1 x omega bracket, 2 x screw, 4 x washer
| Power supply: | 100-240 V AC, 50/60 Hz |
| Power consumption: | 45 W |
| IP classification: | IP20 |
| Power connection: | Mains input via IEC connector (M) mounting version power supply cord with safety plug (provided) |
| Lamp type: | LED lamp |
| LED: | 4 x 10 W high-power 6in1 HCL RGBWA/UV (homogenous color mix) |
| Max. TILT movement: | 220° Exact positioning (16 bit resolution) |
| Max. PAN movement: | 540° Exact positioning (16 bit resolution) |
| DMX channels: | 16; 18 |
| DMX input: | 1 x 3-pin XLR (M) mounting version |
| DMX output: | 1 x 3-pin XLR (F) mounting version |
| Cooling: | Cooling fan |
| Control: | DMX; stand-alone; Sound to light via Microphone; Master/slave function |
| Preprogrammed in: | Light´J; LED PC-Control 512; EASY SHOW 1; Light Captain |
| Beam angle: | 24° |
| Beam angle (1/2 peak): | 24° |
| Beam angle (1/10 peak): | 42° |
| Illuminance in Lux (lx): | Red (R) 3m: 59 lx, 6m: 16 lx Green (G) 3m: 145 lx, 6m: 41 lx Blue (B) 3m: 29 lx, 6m: 8 lx Cold white (CW) 3m: 136 lx, 6m: 37 lx Amber (A) 3m: 47 lx, 6m: 13 lx Ultra violet (UV) 3m: 1 lx, 6m: 1 lx All 3m: 376 lx, 6m: 103 lx |
| Housing color: | Black |
| Display type: | 4 digit 7-segment LED display |
| Dimensions: | Width: 14,5 cm Depth: 14 cm Height: 18 cm |
| Weight: | 1,76 kg |
| Legal specifications | |
| Special product: | Not designed for household room illumination |
| Intended use: | Show effect lighting |
