BLOCK AND BLOCK ALFA-100 Truss lifter 400kg 8m
BLOCK AND BLOCK ALFA-100 Truss lifter 400kg 8m
BLOCK AND BLOCK ALFA-100 Truss lifter 400kg 8m
BLOCK AND BLOCK ALFA-100 Truss lifter 400kg 8m

BLOCK AND BLOCK ALFA-100 Truss lifter 400kg 8m

SKU: 5900043H

6.640,23 €
IVA included.
Product is out of stock.

Add to wishlist



High-quality truss lift for loads up to 400 kg, made in EU

  • Five-part telescopic ground support
  • Safety bolts to lock the different sections at different heights
  • Locking bolts in the base area to lock the booms
  • Booms with adjustable spindle and steel plate with non-slip rubber base
  • Corrosion protection through epoxy coating
  • Water level to ensure a vertical position
  • Earthing connection
  • Transport rolls to move the lift when retracted
  • AL-KO 1201 PLUS winch: maximum load 1350 kg with automatic holding brake
  • Galvanized steel ropes 7x19+1, manufactured in compliance with the standard 13414-1:2004, tensile strength 1770N/mm2
  • Material: Carbon steel S-275-J0H, manufactured in compliance with the standards EN10219 and EN10305.5
  • Adjustable height


Maximum carrying capacity:400 kg
Minimum load:40 kg
Height:Maximum: 800 cm above 5 sections
Minimum: 201 cm
Steel rope:Ø 7 mm
Type (general stands):Truss lifter
Weight:268,00 kg
Brand BLOCK AND BLOCK
