EUROLITE DXT-SP 1in/4out PRO DMX RDM Splitter
EUROLITE DXT-SP 1in/4out PRO DMX RDM Splitter
EUROLITE DXT-SP 1in/4out PRO DMX RDM Splitter
EUROLITE DXT-SP 1in/4out PRO DMX RDM Splitter
EUROLITE DXT-SP 1in/4out PRO DMX RDM Splitter

EUROLITE DXT-SP 1in/4out PRO DMX RDM Splitter

SKU: 70064867



RDM-capable DMX splitter, 1in/4out with signal boost

  • DMX splitter for splitting one DMX input signal to 4 DMX outputs
  • Input and feed-through output are duplicated on the front and rear panel and connected in parallel
  • Switchable filter mode allows all RDM data to be filtered out in order to prevent problems when using fixtures intolerant of RDM
  • Bypass function to process signals from older devices similar to DMX signals
  • Output frequency adjustable: 22/44 Hz
  • Switchable termination resistor
  • Each DMX output with active signal processing
  • Outputs galvanically isolated
  • Each DMX output can be connected to 32 DMX devices
  • Control via RDM
  • DMX feed-through for up to 32 further DMX devices
    RDM For bidirectional communication over the DMX line
    RDM switchable to prevent problems when using fixtures without RDM
  • Built with NEUTRIK connector
  • Made in Germany
  • DMX fail mode (hold; blackout; null)

Package contents

  • 1 x device, 1 x external mains adapter, 4 x foot, 1 x user manual


Power supply:100-240 V AC, 50/60 Hz
12 V DC 1 A
Power consumption:3,6 W
Power connection:Mains input via 4-pin screw plug connector (M) mounting version power supply cord with AC adapter (provided)
DMX input:2 x 3-pin XLR (M) mounting version
DMX output:4 x 3-pin XLR (F) mounting version Separate (galvanic) with active signal processing
2 x 3-pin XLR (F) mounting version Bypass
Control:RDM
DMX features:DMX feed-through for up to 32 further DMX devices
RDM For bidirectional communication over the DMX line
RDM switchable to prevent problems when using fixtures without RDM
DMX fail mode:Hold; blackout; null
Use of brands:Built with NEUTRIK connector
Dimensions:Width: 27,5 cm
Depth: 10 cm
Height: 4,1 cm
Weight:1,21 kg
