Capture - 2024 Solo Edition

Capture - 2024 Solo Edition
Designing with Capture
Whether you're looking to create a simple 2D sketch or a full-blown 3D plot, Capture has you covered. Try as many fixtures as you need, at different hanging positions and with different gels or gobos. Adapt easily to any set design changes or sudden new restrictions. Do even more with Capture's impressive 3D model import capabilities and excellent integration with other lighting control and design products.

Documentation comes easy
Great plots and reports are only a click away in Capture! Design changes instantly update plots and reports, which saves you from having to redo any paperwork. Filter, gobo, focus and patching information appears automatically for all fixture types. With a high readability and a wide range of configuration options you have total control of your paperwork. You can also add some personalisation for that extra professional touch!

Visualise with brilliance
Bring lighting, media and motion into your visualisation. Our rendering engine's outstanding colour accuracy and amazing performance will impress you right away! With a complete library of lighting fixtures, trusses, LED panels and video projectors you have everything you need to make your ideas come to life. When your design is complete you can render it to high quality image and video files. You can also export Capture's unique, stand-alone, presentations which deliver full interactivity with your design.

Specifications related to Design

Model file import formats:glTF
DWG/DXF
MVR
Cinema 4D
SketchUp
OBJ
3DS
Model file export formats:DWG/DXF
glTF
MVR
Data file import formats:CSV
CSV, ETC EOS flavour
Data file export formats:CSV
XML for Hog
XML for grandMA 2
USB devices:3Dconnexion Space Mouse


Specifications related to Visualisation

Video capture devices:Any with Windows (Media Foundation) drivers
Any with macOS drivers
Ethernet DMX protocols:Art-Net
CITP
Compulite VC
High End Hog visualizer connectivity
ETC Net 2
MA-Net2 (Windows only, MA software version 2.9+)
MA-Net3 (grandMA3 viz-key)
sACN
USB DMX devices:EntTec DMX USB Pro
EntTec DMX USB Pro Mk2
Streaming video media protocols:NewTek NDI
CITP/MSEX
Green Hippo HMap 3
Streaming laser media protocols:CITP/CAEX
LaserAnimation
Pangolin Beyond
Motion tracking protocols:Blacktrax RTTrP
Kinesys K2
PosiStageNet
Camera control protocols:OSC
