Luminex - GigaCore 18t – 16x1G – 2x10G(SFP+) The GigaCore 18t is a 10 Gigabit Ethernet switch for professional touring applications in lighting, audio and video with a frequent tear-down & built-up requirement or for any other application where ruggedized connectivity is necessary. It is designed to support the most advanced AV protocols out of the box and is the backbone for a converged network, allowing multiple applications to co-exist on the same network.
Robust yet silent design
A robust yet silent design allows you to use GigaCore in any AV environment. Fans are speed controlled to have minimal noise impact and guarantee a long-life operation. This allows you to place the GigaCore in the most quiet environments like theaters and studio’s.
Key features
Most suitable applications: Touring applications PoE: PoE ++ Optional RLinkX (Link redundancy): Yes Groups (VLAN segmentation): Yes MultiLinkX (Link aggregation): Yes (With future FW upgrade) Profile manager: Yes Memory: Flash 1Gb RAM – 8Mb NOR flash 4Gb EMMC storage MAC address table: 16384 entries Address learning / Aging: Self learning, Auto aging Switching throughput: 72Gbps Jumbo frames: MTU up to 12000 IGMP support: Yes (V1/V2/V3) IGMP snooping: Yes, enabled by default Port sensing: Auto negotiation Auto crossover: MDI / MDIX Auto sensing: Full or Half Duplex (Gigabit is Full Duplex)
