Luminex - LumiCore - 64 processing engines

Luminex - LumiCore
LumiCore allows you to merge and route up to 64 x 4 input sources toward 64 newly defined universes. This way, LumiCore becomes the ideal solution to isolate your control setup on a festival, a theater or in a TV studio.

As technology is evolving towards full networked solutions (ArtNet or sACN directly to the fixtures), LumiCore provides all the flexibility of the LumiNode but then directly on the network, with up to 256 input universes merged and routed towards max 128 output universes. All of this with extreme low latency.

The engine technology allows you to merge in HTP, LTP, Backup, Switch, Crossfade or custom mode, with different triggers that can be assigned even on a per channel basis. In large pixel mapping applications LumiCore is the ideal bridge to merge different control sources into new network streams.

KEY FEATURES

Mount one or two units in a 1U rack space
The unit is robust and thus ideal for touring applications
64 processing engines
The M10 insert and safety ear make it easy to mount it safely on a truss


Rack or truss mountable half 19” unit
RGB LED for activity indication
2 x EtherCon network port @ 1Gbps with integrated switch
Link/Speed LED indication per Ethernet port
RGB Mode LED indication per Ethernet port
Color display and control jog for fast configuration
Contact closure as trigger
PoE powered (IEEE 802.3af)
Internal universal power supply with Neutrik PowerCon True1
Robust steel enclosure with M10 insert and protection ear
